QSFP56 200G AOC模块设计用于200千兆以太网链路,多模光纤长度可达30米。该模块有4个独立的电气输入/输出通道,每个通道的工作速率为53.125Gb/s。该AOC包括一个在四个850nm波长上工作的发射器/接收器单元。
该模块的发射器路径包含一个双向PAM4定时器ASIC,集成了一个4通道调制器驱动器和4个外部调制激光器。在接收器路径上,有4个光电二极管和一个4信道线性TIA阵列以及PAM4重新定时器。模块的电气接口符合IEEE 802.3bs定义的200GAUI-4接口。
Supports 212.5Gbps
Single 3.3V power supply
Power dissipation: commercial version (Each)< 5W
4x26.5625GBd (PAM4) electrical interface
Commercial case temperature range of 0°C to 70°C
VCSEL transmitter
PIN and TIA array on the receiver side
I2C interface with integrated Digital
Diagnostic Monitoring
Safety certification: TUV/UL/FDA*1
