Slot capacity

2 semi slots for 1+1 system control and 2 semi slots for 1+1 power supply card
（1）Configuration 1: 7 complete slots OTN service cards.
（2）Configuration 2: 6 complete slots OTN service cards and 3 semi slots WDM cards (OMD, OA, OLP)
（3）Configuration 3: 4 complete slots OTN service cards and 7 semi slots WDM cards (OMD, OA, OLP)
（4）Configuration 4: 15 semi slots WDM cards (OMD, OA, OLP)

Line Side Interface

OTU2/2e / OTU4 / OTUC2

Client Side Interface

GE/FE, 10GE LAN/WAN, 40GE, 100GE
STM-1/4/16/64, OC-3/12/48/192
OTU2, OTU2e, OTU3, OTU4

Power Supply

Support 1+1 backup DC power supply;
Input voltage range: -40V～-72V

Power Consumption

Max.1100W

Dimension(W*H*D)

444.5mm * 222mm * 241.5mm

Environment

Working temperature: 0℃～40℃;
Storage temperature: -40℃～70℃;
Relative humidity: 10%～90%, no condensing;
