With society’s development, people demand more information through VR, HDTV, HD video, 3D games, cloud computing, big data, the Internet of things, cloud storage, etc. as new applications keep showing up. There is no doubt that the data boom will raise the bandwidth capability of the Internet. Usually, the subscriber’s closest access network becomes a bottleneck, which indicates that the access networks’ upgrading and rebuilding are essential since the original copper cable accessing (ADSL or Cable Modem) cannot satisfy the demand anymore.

FTTH (Fiber to the Home) can provide higher bandwidth for users to meet different demands of voice, video, and data with fiber as the transmission medium, which will gradually replace copper accessing technology. PON (Passive Optical Network) is recognized as the best FTTH network accessing technology in the industry with no active power devices and passive devices between the local and user sides. Due to its advantages such as high bandwidth, good network stabilization, the convenience of management and maintenance, and low cost, the FTTH solutions become the current preferred network accessing solution with consistent approbation from big operators worldwide.

FB-LINK specializes in PON technology, and product development has a wide range of product series and can provide users with end-to-end product solutions.

Program overview:

(1) CATV front-end computer room: 1550nm optical transmitter with special technology combined with optical amplifier can effectively increase the output power of the transmitting end and extend the transmission distance;

(2) Sub-front-end computer room: The video multiplexer adopts high-power double-clad erbium-ytterbium co-doped amplification technology, passive PON multiplexing technology, and cooperates with OLT equipment to solve multi-service two-way single-fiber transmission and save fiber resources;

(3) User terminal: 100M/1000M ONU equipment, supporting multiple services such as the Internet, telephone, and cable television.

Program features:

1) The schematic diagram of this solution is the CATV+PON system, and the overall solution can be flexibly customized according to user needs, including EOC+PON system, WDM-PON system, etc.;

2) Solve multi-service two-way single-fiber transmission without additional equipment;

3) Meet various access requirements such as voice, high-definition IPTV, CATV, and dedicated lines;

4) Fiber to the home, through EPON/GPON technology, 1000M to the home can be achieved.

FTTH Solution and Product

FB-LINK provides FTTH solution, a new generation passive fiber network product solution based on the PON system network, meets relative national and international standards of GPON and EPON, and meets the transmission requirement of high-speed internet, voice, and video services. This solution not only can provide the last kilometer access with fiber for all kinds of network operators, but also can be applied on customer professional network for various industries like broadcast and television access network, video monitoring network, enterprise local area network, and servers in customer private network of different industries such as radio and television, transportation, energy sources, electric power, finance, and government.

Introduction of FTTH solution based on PON system:

OLT of the local side (Machine room) is the core of the PON system. It provides high-speed uplink interfaces for information access, such as voice, data, and PON interfaces for the passive optical distribution network. OLT is also the control center of the PON system, by which the network management system can accomplish operations, management, and maintenance of the PON system.ONU of the user side provides an interface for data, internet video, and VOIP. By applying Ethernet, GEM protocol, etc. to implement transparent transmission of user data in the PON system.

ODN network between OLT and ONU, a passive optical distribution network consisting of optical splitter and optical fiber, distributes and converges optical signals. ODN network forwards downstream data to each ONU terminal and aggregates upstream data into the OLT device. Based on the actual application environment, it can use one splitter solution or two cascaded splitters solution.

FB-LINK manufactures EPON and GPON products that meet various application scenarios, including cassette type, module inserted type, mini type and outdoor type of OLT products, SFU type, HGU type, and CATV type of ONU products, and so on.There are types of the cassette, compact, module inserted and outdoor of OLT products, the series of cassette and mini type of OLT with 1U height can be installed in 19-inches standard rack and has characteristics of compactness, convenience, high performance, easy to use and deploy, which meets the requirement of volume and performance in the compact machine room.Mini type OLT is smaller and more convenient, which meets the installment requirement in corridor and device cabinet.

Module inserted OLT can be deployed with different amounts of modules according to application requirements, which has a high level of integration and flexibility, easy to manage and configure, a product that meets access demand of medium-size network large-scale network with high cost-effectiveness.Outdoor type OLT uses cast aluminum IP65 waterproof shell and is applicable in the pole, floor stander, and corridor application scenarios.

These products are mainly for two-way network construction of broadcast television network, the “last kilometer” of fiber access provided by telecom operators, big customer broadband access solution, and also apply to high definition video monitoring system and three-in-one network including network, voice and video of government, public security and network of large enterprises.

Related products as follows:

GPON Product: different combinations of two active transmission equipment, including namely-Optical Line Termination (OLT) and Optical Network Unit(ONU).

• GPON OLT: Cassette OLT and rack-mounted OLT (Module inserted)

• GPON ONU: Data type, data + voice type, data + WIFI type, data + voice + WIFI

EPON Product: a device that serves as a provider endpoint of a passive optical network, multiplexing between the conversion devices on the other end of that network (called either optical network terminals or optical network units).

• EPON OLT: Cassette OLT, rack-mounted OLT (Module inserted), outdoor OLT

• EPON ONU: Data type, data + voice type, data + WIFI type, data + voice + WIFI
